Type Of Glass | Filament Diameter (um) | Linear Density (Tex) |
ECR | 17-24 | 1200, 2400, 4800, 9600 |
Item | Description |
YN-Uni-Directional Fabric ( 0° or 90°) | The density of 0° Uni-Directional Fabric can be 300g/m²~900g/m² and density of 90° can be 150g/m²~1200g/m² |
YN-Biaxial Fabric (0°/90° or ±45°) | The density can be 300g/m²~2400g/m² , can be wich layer of Chopped Strands. |
YN-Triaxial Fabric (0°/+45°/-45°) / (+45°/+90°/-45°) | The density can be 450g/m²~1800g/m² , can be wich layer of Chopped Strands. |
YN-Quadraxial Fabric (0°/+45°/90°/-45°) | The density can be 600g/m²~2000g/m² , can be wich layer of Chopped Strands. |
Item | Standard Weight(g/m2) | Width(mm) | Loss On Ignition(%) | Moisture(%) | Resins |
YN-EMC225 | 225 | 1040/1270/2080 ≤3300 | 2-6 | ≤0.2 | UP VE EP |
YN-EMC300 | 300 | 1040/1270/2080 ≤3300 | 2-6 | ≤0.2 | UP VE EP |
YN-EMC380 | 380 | 1040/1270/2080 ≤3300 | 2-6 | ≤0.2 | UP VE EP |
YN-EMC450 | 450 | 1040/1270/2080 ≤3300 | 2-6 | ≤0.2 | UP VE EP |
YN-EMC600 | 600 | 1040/1270/2080 ≤3300 | 2-6 | ≤0.2 | UP VE EP |
YN-EMC900 | 900 | 1040/1270/2080 ≤3300 | 2-6 | ≤0.2 | UP VE EP |
Item | Weight(g/m2) | Fabric(g/m2) | Chopped strand mat (g/m2) | Wet speed(≤S) |
YN-WRM 500/300 | 800 | 500 | 300 | 60 |
YN-WRM 500/450 | 950 | 500 | 450 | 60 |
YN-WRM 600/300 | 900 | 600 | 300 | 60 |
YN-WRM 600/450 | 1050 | 600 | 450 | 60 |
YN-WRM 800/300 | 1100 | 800 | 300 | 60 |
YN-WRM 800/450 | 1250 | 800 | 450 | 60 |
YN-MFM 800(0°, 90°)/400 | 1200 | 800 | 400 | 60 |
YN-MFM 800(0°, 90°, +45°, -45°)/450 | 1250 | 800 | 450 | 60 |
