fiberglass fabric for ship
Usually fiberglass woven roving is often used for shipbuilding, and fiberglass plain cloth is more used for ship repair.
Fiberglass boats consist of braids alternated with any number of resins such as polyester, vinylester or epoxy.
The advantages of this method include relatively low maintenance, high strength, ease of repair,
 and generally lower cost compared to other shipbuilding materials.
Related Products
Application of
Fiberglass Fabric

The glass fiber cloth is light and high strength, which can effectively improve the reserve buoyancy of the hull; the structure and function are integrated, and the general material forming process is also the structural forming process; corrosion resistance, can meet the requirements of harsh marine environments such as high salt, high humidity, and ultraviolet rays; Aging, can meet the long life requirements of ships.

Product Specification

Fiberglass woven roving
  Item
TEX   Count Of Cloth(root/cm)  Unit Area Mass(g/m) Breaking Strength(N) Width(mm)
Wrap Yarn Weft Yarn Wrap Yarn Weft Yarn Wrap Yarn Weft Yarn
YN-EWR200
  180 180 6.0   5.0 200±15 1300 1100 30-3000
YN-EWR300
  300 300 5.0   4.0 300±15 1800 1700 30-3000
YN-EWR400
  576 576 3.6   3.2 400±20 2500 2200 30-3000
YN-EWR500
  900 900 2.9   2.7 500±25 3000 2750 30-3000
YN-EWR600
  1200 1200 2.6  2.5 600±30 4000 3850 30-3000
YN-EWR800
  2400 2400 1.8   1.8 800±40 4600 4400 30-3000
YN-CWR200 180 180 6.0 6.0 200±15 1150 1000 30-3000
YN-CWR400 480 500 4.0 3.8 385±30 2000 2200 30-3000
YN-CWR600 1300 960 2.6 2.6 600±45 3500 3000 30-3000
YN-CWR800 2200 1760 2.0 2.0 810±40 4000 3600 30-3000
Fiberglass plain cloth
  Item Weave Structure   Density counts/cm Weight (±5%) Thickness(±10% Color
Warp Weft g/m2 Oz/yd2 mm inch
  YN-7628 Plain  18  12 300 60 0.20 0.008 White
  YN-280 Plain 12 9 450 60 0.30 0.012 White
  YN-310 Plain 12 10 300 60 0.32 0.013 White
  YN-3732 Twill 18 10 450 60 0.43 0.017 White/yellow
  YN-600 Plain pane 15 14 300 60 0.60 0.023 White/yellow
  YN-3784 Satin 18 12 450 60 0.90 0.035 White/yellow
 YN-3788 Satin 18 12 400 60 1.65 0.067 White/yellow
Still can't find what you're looking for?
Please contact our consultants for more available products.
Production Process
Fiberglass fabric has uniform distribution, uniform tensile strength, good vertical performance, etc.
The product is fresh production, furance fibergalss direct roving with higher tensile strength
Inspection report
HD can provide professional TDS, REACH MSDS, CE, BV, ISO, SGS certification, and can also do corresponding third-party certification according to customer requirementsneed.
Contact Us

Why choose us

Freight service
HD Fiber Glass supports multiple shipping methods (sea shipping, air shipping, rail shipping), if you want to receive your glass fiber samples as soon as possible, we can recommend the best shipping method for you.
About the delivery time of the order goods:
If we have stock , can delivery in 7 days ; if without the stock, need 7~15 days !
Support to make documents according to customer requirements, Form F, Form A, Form E.

Team
Our mission is new materials create a better life.
Welcome business cooperation by our high quality products and sincere service,to win the beautiful tomorrow together!
Package
HD Glass Fiber woven roving cloth could be produced into different widths, each roll is wound on a suitable cardboard tubes with inside diameter of 100mm,then put into a polythylene bag,fastened the bag entrance and packed into a suitable cardboard box. Upon to customer's request, this product could be shipped either with carton packaging only or with packaging, In pallet packaging, the products could be horizontally put on the pallets and fastened with packing straps and shrink film.
Delivery Detail: 15 days after receiving the deposit.
